Wuko 6050 Sheet Metal Mini Uber Bender

The WUKO 6050 Mini Uber Bender is a compact, handheld sheet metal bending tool designed for precise bends up to 100°, especially along small radii. Equipped with an angled bending disc, the WUKO 6050 provides excellent control when forming tight curves, working with spring-back materials, and bending delicate sheet metal surfaces.

With an adjustable bending height ranging from 5 mm (3/16") to 50 mm (2"), the WUKO 6050 is ideal for curved flashings, architectural sheet metal details, and custom metal roofing applications. Its two roller stops and two support rollers provide additional stability and guidance during bending, while an engraved measurement scale and removable handle allow for easy adjustments and comfortable operation.

Features & Benefits

• 100° Bending Capability: Forms precise bends from 0° to 100°, helping compensate for spring-back when working with certain sheet metals.
• Small Radius Bending: Compact design is especially suited for bending along tight curves and small radii.
• Adjustable Bending Height: Accommodates bending heights from 5 mm (3/16") to 50 mm (2").
• Angled Bending Disc: Provides controlled bending performance while helping protect delicate and coated sheet metal surfaces.
• Dual Roller Stops: Two roller stops help maintain consistent positioning along the sheet metal edge.
• Dual Support Rollers: Two support rollers provide additional stability and material support during bending.
• Engraved Measurement Scale: Inch scale on the upper shaft allows for accurate bending height adjustments.
• Removable Handle: Provides convenient handling and can be removed when working in confined spaces.
• Spring-Back Material Compatibility: Extended bending angle helps achieve accurate bends when working with materials that tend to spring back.
• Compact & Lightweight: Weighs approximately 2 lbs for comfortable handling and portability.
• Versatile Applications: Ideal for curved roof flashings, architectural sheet metal, and detailed metal roofing fabrication.
• Manual Operation: No electrical power required.

Technical Specifications

• Bending Angle: 0°–100°
• Minimum Bending Height: 5 mm (3/16")
• Maximum Bending Height: 50 mm (2")
• Bending Capacity: 0.80 mm (22 ga) for common sheet metals
• Weight: 2 lbs (0.90 kg)
• Bending Mechanism: Angled bending disc
• Roller Configuration: Two roller stops and two support rollers
• Measurement Scale: Centimeter or Inch
• Handle: Removable
• Operation: Manual

WUKO 2050 vs. WUKO 6050 Mini Bender

Both tools are designed for precise sheet metal bending along small radii, with adjustable bending heights up to 2" (50 mm). The primary difference is their bending mechanism and maximum bending angle.

• WUKO 2050 Mini Bender: Bends from 0° to 90° using a traditional bending roller configuration. Ideal for inside and outside radius bends.
• WUKO 6050 Mini Uber Bender: Bends from 0° to 100° using an angled bending disc. Ideal for small radius work, delicate surfaces, and materials requiring additional bending to compensate for spring-back.
